SITRANS FM MAG 1100

Posted on by
Home >> Process Instrument >> Flow Measurement >> Electromagnetict >> Sensor

     SITRANS FM MAG 1100 is a sensor in stainless steel with highly resistant liners and electrodes which fit even the most extreme process media.

Benefits

  • Measures temperature with a linear output signal
  • High accuracy across entire ambient temperature range
  • Reduces plant noise
  • Alarm signal for sensor break or short circuit according NAMUR 43
  • Explosion protected executions for US, Canada and Europe
  • Slim design, ideal for upgrade of installed Pt100 probes with a 4 .. 20mA signal
  • Rugged design, fully potted electronic

Technical Overview

Measuring Range 0 to 10 m/s
Nominal Sizes From DN 2 to DN 100 (1/12" to 4")
Accuracy
    0.2 % ±1 mm/s
    0.4 % ±1 mm/s (PFA)
Operating Pressure Max. 40 bar (Max. 580 psi)
Ambient Temperature From -40 to 100 oC (-40 to 212 oF)
Medium Temperature From -30 to 200 oC (-22 to 390 oF)
Liners
    Ceramic
    PFA
Electrodes
    Platinum
    Hastelloy
Material Stainless Steel AISI 316L (1.4404)
Approvals ATEX - 2 GD Zone 1, FM Class 1 div 2
Application Process Industry, Chemical Industry, Pulp & Paper Industry

Catalog :

SITRANS FM MAG1100
