Think of it as the benchmark for performance, maintained over a wide range of flows
- FCS500 sensor + FCT020/FCT040 transmitter = FC520/FC540 flowmeter system
- FCS500 sensors combine with compact or remote transmitters
- Tube health check supports predictive maintenance
- Viscosity function and capability to manage high viscous process fluids
- Accurate density measurement and up to four fraction (concentration) measurements
Benefits
- Choose your sensor based on your applications need and afterwards select the transmitter model based on the communication and performance requested.
- The modular concept allows to find the right fit for your need.
- Maximum accuracy due to calibration facility accredited according to ISO/IEC 17025
- Tube health check (diagnostic verification) alerts of potential performance issues doe to process events, e.g. unwanted gas or vapor breakout & solid deposits building up in the tubes.
- High measurement sensitivity & intelligent dynamic range keeps the measurement active even in demanding high damping cases.
- Precise flow rate measurement of fluids and gases, multi-phase fluids and fluids with specific gas content using the Coriolis principle.
Technical Overview
| Measuring Range | 0.8 - 255000 kg/h |
| Maximum Process Temp. |
|
| Wetted Materials | 316L/1.4404 |
| Sensor Size | DN10 – DN80 |
| Maximum Pressure |
|
| Approvals | |
|
|
| Hyegienic |
|
| Marine (class 2 and 3) |
|
| Features |
|
Catalog :
SITRANS FC520/540
