Generous in its size whilst delivering on durability and the performance required in large scale processes
- FCS700 sensor + FCT020/FCT040 transmitter = FC720/FC740 flowmeter system
- FCS700 sensors combine with compact or remote transmitters
- Nominal flow rates from 250 000 kg/h to 900 000 kg/h
- Gas void fraction and net oil computing functions deliver in multi-phase applications
- High power tube driver for dependable measurements in high damping applications
Benefits
- Choose your sensor based on your applications need and afterwards select the transmitter model based on the communication and performance requested.
- The modular concept allows to find the right fit for your need.
- Maximum accuracy due to calibration facility accredited according to ISO/IEC 17025
- Tube health check (diagnostic verification) alerts of potential performance issues doe to process events, e.g. unwanted gas or vapor breakout & solid deposits building up in the tubes.
- High measurement sensitivity & intelligent dynamic range keeps the measurement active even in demanding high damping cases.
- Precise flow rate measurement of fluids and gases, multi-phase fluids and fluids with specific gas content using the Coriolis principle.
Technical Overview
| Measuring Range | 125 - 1100000 kg/h |
| Maximum Process Temp. |
|
| Wetted Materials |
|
| Sensor Size | DN100 – DN200 |
| Maximum Pressure |
|
| Approvals | |
|
|
| Hyegienic | |
| Marine (class 2 and 3) |
|
| Features |
|
Catalog :
SITRANS FC720/740
