SITRANS FM MAG 5000

Posted on by
Home >> Process Instrument >> Flow Measurement >> Electromagnetic >> Transmitters

     The SITRANS FM MAG 5000 is a microprocessor-based transmitter, which is a truly robust all-around solution for a wide variety of applications.

Benefits

  • Cost-effective transmitter with high performance
  • The transmitter is rugged, suitable for universal applications and has high measurement accuracy
  • Multiple function outputs for process control
  • Display and keypad available in several languages
  • SITRANS FM portfolio – our integrated platform enables flexible use of the MAG 500/ 6000 transmitter for all products (MAG 5100/ 3100/ 1100):
    • Unique SensorProm technology – stores critical, sensor-specific data and passes it to the transmitter. This allows a simple, flexible commissioning of the sensor.
    • Plug & Play – allows easy on-site replacement and commissioning of the transmitter in just minutes
    • “Hot swapable” – exchangeable during operation
    • Mounting flexibility – compact or separate installation possible
    • Validated calibration ensures accurate flow measurement. Each Siemens flowmeter is calibrated in facilities that are individually accredited to ISO / IEC 17025.
    • Service and diagnostics – Designed for MAG on-site verification with traceable certification. Regular calibration of the SITRANS FM Verificator ensures accuracy in the field

Technical Overview

Accuracy 0.4 % ±1 mm/s
Input / Output
    1 Current Output
    1 Digital Output
    1 Relay Output
Communications HART
Display Background illumination with alphanumeric text, 3 x 20 characters
Enclosure
    IP67 (NEMA 4x/6)
    IP20 (NEMA20
Power Supply
    12-24 V a.c./d.c.
    115-230 V a.c.
Ambient Temperature From -20 to 50 oC (-4 to +122 oF)
Approvals
    MI-001
    Danak
    PTB
    OIML R49
Ex-Approvals FM/CSA Class 1, Div 2
Application Water and Wastewater, General Process Industry, Food & Beverage Industry

Catalog :

SITRANS FM MAG 5000
